electronic test equipment,tensile tester.
9 Years
| Ask Lasest Price | |
| Brand Name : | PTE |
| Model Number : | WA-600C Electronic Power Analog Universal Test equipment |
| Certification : | CE |
| Payment Terms : | L/C, T/T, Western Union |
| Delivery Time : | wooden case |
Applications:
WA-C Series Testing machine are guaranteed to meet ISO15579-2000, ISO679, ISO7438-1985, ISO6892, EN100021-1-2001, ASTM E8M, JIS Z2241-1998, ISO75000-1, ISO4012, ISO10065 and other international and national specifications, which are suitable for tension, compression, bending, shear and other tests by adding different test fixture for metal and non-metal materials. It adopts hydraulic power pack to drive the piston in the oil cylinder to provide testing load. This model can show test load by analog dynamometer, also by using pressure transducer and photoelectric encoder, the computer is timely showing the testing parameters like testing load, piston stroke, deformation of specimen and various kinds of testing curves etc. This machine is manual control mode and the computer with strong function software does data processing and issues the test reports
| Model | WA-600C |
| Max. Load | 600KN |
| Load accuracy | ≤±1% |
| Strain accuracy | ≤±0.5% |
| Ram stroke (mm) | 150 |
| Displacement Accuracy | ≤±0.5% |
| Max. Distance Between Two Fulcrums of Bending Test (mm) | 600mm |
| Effective tensile space | 690mm |
| Dimension | 890×580×2280 |
| Approx Weight (KG) | 2500 |
Three Star Service :
*First Star---Pre-service
24 Hours online service for your consult
Help choose right model,and a series of service,person,advise.
*Second Star---Middle Service
--Give you best offer
--Provide discount for many sets order
--Do customer's request
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
. *Third Star---After serivce
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Provide newest software vision when update
--Remote control technical consult
--Free installation DVD
--Maintenance plan
|
|
