| Brand Name : | PTE |
| Model Number : | Servo Electro-hydraulic Universal Testing Machine Model WAW-2000C |
| Certification : | CE |
| Payment Terms : | L/C, T/T, Western Union |
| Delivery Time : | wooden case |
Applications
--CE ISO ISO679 ISO7438-1985,ISO6892, EN100021-1-2001, ASTM E8M, JIS Z2241-1998,international ,national specifications.
--Suitable for tension compression bending shear and others by adding different test fixture for metal/non-metal materials.
--Adopts hydraulic power pack, using load cell and photoelectric encoder.
--The software based on Windows system can make automatic calculating of test results. i. e tensile strength.
--Field are iron factory, lab machinery ect.
Features
1. Load:adopting load cell to ensure high accuracy, reliability and
consistency;
2. Displacement:adopts optical encoder with high accuracy and
stability;
3.Strain:Adopt high accuracy electronic extensometer
4.Compact structure: The machine has four column and two screw with strong stiffness;
5.Clamp automatically: uses hydraulic grips with reliable holding;
6.Multi-protection: protection of over-load by software and hardware; position-limited protection of piston and lower crosshead;
7.Test data: uses Access, Excel and other such kind software
Specifications
| Model Specifications | WAW-300E | WAW-600E | WAW-1000E | WAW-2000E |
| Max. Testing Load (kN) | 300 | 600 | 1000 | 2000 |
| Load resolution | 1/200000 | |||
| Load Accuracy | ≤±1% from 2% to 100% of full scale | |||
| Displacement Accuracy | ≤±0.5% | |||
| Displacement resolution | 0.001mm | |||
| Strain accuracy | ≤±0.5% | |||
| Strain resolution | 0.0001mm | |||
| Control Mode | Servo Control | |||
| Load frame Type | 4-column and 2-screw structure | |||
| Stress rate range | 1—60(N/mm2)S-1 | |||
| Strain rate range | 0.00025/S—0.0025/S | |||
| Max. tensile space (Including piston Travel) mm | 690 | 750 | 750 | 1000 |
| Max. Compression space (mm) | 570 | 620 | 600 | 850 |
| Round specimen grip (mm) | Dia 9-32 | Dia13-40 | Dia20-60 | Dia20--80 |
| Flat Sample Clipping Thickness (mm) | 0-15 | 0-15 | 0-30 | 10-40 |
| Ram stroke (mm) | 250 | 250 | 250 | 250 |
| Max. Distance Between Two Fulcrums of Bending Test (mm) | 480 | 600 | 400 | 720 |
Three Star Service :
*First Star---Pre-service
24 Hours online service for your consult
Help choose right model,and a series of service,person,advise.
*Second Star---Middle Service
--Give you best offer
--Provide discount for many sets order
--Do customer's request
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
. *Third Star---After serivce
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Provide newest software vision when update
--Remote control technical consult
--Free installation DVD
--Maintenance plan
|
|
